The ZVAK has been superceded by the Pneuvak Vacuum Sealer (ZVAK 2.0)
This unit requires a separate compressed air source capable of providing 80 PSI of clean, dry air
23.5" Maximum seal length
406 Stainless steel body
5mm nichrome heating element on top and bottom jaw standard
Single high flow stainless steel retractable nozzle
Easy to use PLC control panel with 8 recipes - multi stage gas flush standard
Ejector vacuum pump which can reach 26" Hg - ideal for clean room applications
Pneumatic safety system with micro switch to prevent operator injury when jaws close
Fuse and breaker protected
Power: 110v/60Hz (220v/50Hz also available)
Wattage/Amps: 2200W / 20A
Foot pedal operated
Footprint: 23.75" x 19.5" x 9.5"
Weight: 82 lbs.
Each vacuum sealer comes with the following accessories:
Foot pedal
Power cord
Operating manual
Warranty: One year parts and labor not including consumables
Optional Equipment:
Nitrogen Gas Generator RM11042
Our Nitrogen Gas Generator (NGG) can be used as a replacement for heavy and bulky Nitrogen gas tanks. Its slick and compact design allows users to integrate this with their current gas flush enabled vacuum sealers without having to worry about it taking up too much space. Also, customers will not have to worry about a depleting Nitrogen gas source, as our NGG produces Nitrogen from a clean compressed air source.
We often refer to the PneuVak machines as the “zVak 2.0” because they are a similar but enhanced version of the zVak. The PneuVak has a few improvements on its predecessor the zVak series, including increased air flow rate which accelerates the vacuum seal and speeds production, as well as an emergency stop button that allows operators to cancel operation at any moment.
PneuVak Air Flow Rate = 7CFM (198L/min)
zVak Air Flow Rate = 5.5CFM (155L/min)
It is important to note that although the air flow rate is greater on the PneuVak machines, the operator will still have the control to protect delicate products by sealing at any point during the vacuum cycle.
Standard features you can expect from both machines are the option for gas flush, stored recipes, stainless steel body, and a retractable vacuum nozzle.
IMPAK still sells and services the zVak series, and we highly recommend them. The PneuVak series has simply been added an enhanced version for those who prefer a faster vacuum and added emergency stop button. Contact us for a recommendation based on your application.
AirZ sealer is great for sealing the following bags.
Heavy Duty Mylar Bags (IronshieldTM Bags)
Mylar Mini Pouches (less than 8" x 12")
Medium Foil Bags (7.5" x 9" ~ 16" x 24")
Large Barrier Bags (18" x 16" ~54" x 48" or length > 24")
ZipSeal Open Zipper End Bags | ZipSeal Tamper Evident Bags
Food Saver Bags (Channel Bags, Special Surface Bags)
Nitrogen Gas Generator (NGG)
The Nitrogen Gas Generator produces Nitrogen gas (N2) from compressed air.
* This module is designed to generate Nitrogen at purities between 95% and 99.5%.
Application: Our NGG can be used as a replacement for heavy and bulky Nitrogen gas tanks. Its slick and compact design allows users to integrate this with their current gas flush enabled vacuum sealers without having to worry about it taking up too much space. Also, customers will not have to worry about a depleting Nitrogen gas source, as our NGG produces Nitrogen from a clean compressed air source.
Compatible Sealers: PNG460ED, ANG460ED, AirZ series, and any custom gas flush enabled vacuum sealers.
Part Number: RM11042
Size: 15.5” x 2.5” x 4.25”
Weight: 5.1 lbs
Spare Parts Kit
(4) 5mm nichrome heating elements
(2) 6 mil x 2" wide PTFE covers with adhesive strips
(2) 10 mil x 0.5" wide PTFE strips with adhesive backing
(2) 10A fuses
(1) 20A fuse
(1) 10mm/8mm wrench
(1) Phillips/Flat stubby screwdrive
